NVIDIA NVS Graphics

Graphics for Video Walls & Multiple Monitors

NVIDIA® NVS graphics provide for up to eight displays in single slot, low power, low profile solutions for demanding professional multi-display environments. With flexible display output connection support, NVS solutions are ideal for a wide range of multi-display deployments.

PRODUCTS

  • Graphic Cards
  • Comparison Chart
design-visualization-nvs-810-graphics-card-3qtr-823-udt

NVS 810

This is the world's most capable digital signage card with lowest TCO, letting you seamlessly drive 8 displays from a single card or combine cards together to form massive signage walls. Discover superior advanced image management using technologies such as NVIDIA® Mosaic and NVIDIA Warp & Blend.

NVS 510 Graphics Card

NVS 510

Power efficient performance with ultra-fast 2 GB on board memory to reliably drive up to 4 displays across varied business environments. NVS 510 also supports advanced DP 1.2 features and 4K resolutions.

NVS 315 Graphics Card

NVS 315

Flexible & Energy efficient low profile solution with 1024 MB on board memory, providing display connectivity to drive any type of dual-display.

NVS 310 Graphics Card

NVS 310

Energy efficient low profile solution with 512 MB/1 GB on board memory to seamlessly drive up to 2 displays.

NVS Desktop Workstation Specifications

NVS 810 NVS 510 NVS 315 NVS 310
Bus Interface PCI Express 3.0 x16 PCI Express 2.0 x16 PCI Express 2.0 x16 PCI Express 2.0 x16
Memory Size 4 GB DDR3 (2GB per GPU) 2048 MB DDR3 1024 MB DDR3 1024/512 MB DDR3
Memory Interface 128-bit (64-bit per GPU) 128-bit 64-bit 64-bit
Memory Bandwidth 28.8 GB/s 28.5 GB/s 14 GB/s 14 GB/s
Form Factor ATX SFF¹ SFF¹ SFF¹
CUDA Processor Cores 1024 (512 cores per GPU) 192 48 48
Display Connectors mini DisplayPort (8) mini DisplayPort (4) DMS59 DisplayPort (2)
Max. Displays per Board 8 4 2 2
Max Digital Display Support 4096x2160 @ 30Hz 3840x2160 2560x1600 (DisplayPort) - 1920x1200 (DVI-I) 2560x1600
Max Analog Display Support 1920x1200 1920x1200 2048x1536 (VGA) 1920x1200
OpenGL 4.5 4.3 4.3 4.3
DirectX 12 12 11 11
Shader Model 5 5 5 5
CUDA enabled Yes Yes Yes Yes
Power & Cooling 68W - Active3 35W - Active3 19.5W - Active3 19.5W - Active3
nView Enabled Yes Yes Yes Yes
DisplayPort Links 8 4 24 2
DVI Links 82 42 25 22
Analog Displays VGA 87 47 26 27
DisplayPort 1.2 Support Yes Yes Yes Yes
Max Displays in DP 1.2 MST node 88 4 2 2
Max Displays in DP 1.2 Stream Cloning mode 32 16 8 8
