Technical Specifications
  NVIDIA GeForce 8200 NVIDIA GeForce 7050 PV and NVIDIA nForce 630a NVIDIA GeForce 7025 and NVIDIA nForce 630a NVIDIA Quadro NVS 210S and NVIDIA nForce 430 NVIDIA GeForce 6150 LE and NVIDIA nForce 430 NVIDIA GeForce 6150 SE and NVIDIA nForce 430 NVIDIA GeForce 6100 and NVIDIA nForce 430 NVIDIA GeForce 6100 and NVIDIA nForce 405
CPU Phenom
Athlon 64 X2
Athlon 64 Sempron		 Athlon 64 X2 Athlon 64 Sempron Athlon 64 X2 Athlon 64 Sempron Athlon 64 X2 Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron Athlon 64 Sempron
Supported Sockets AM2+ AM2 AM2 939, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2 939, 754, AM2
GeForce Boost Technology Yes No No No No No No No
HybridPower™ Technology Yes No No No No No No No
NVIDIA PureVideo HD Yes No No No No No No No
NVIDIA PureVideo Yes Yes No Yes Yes Yes Yes Yes
DirectX 10 Support Yes No No No No No No No
DirectX 9.0 Shader Model 3.0 Support Yes Yes Yes Yes Yes Yes Yes Yes
Integrated HDMI Yes Yes No No No No No No
HDCP Support Yes Yes Yes No No No No No
TV Encoder No Yes* No Yes Yes sDVO -> TV sDVO -> TV No
DVI Support Yes Yes Yes Yes Yes sDVO -> DVI sDVO -> TV No
PCI-Express 1x16
3x1		 1x16
3x1		 1x16
3x1		 1x16
2x1		 1x16
2x1		 1x16
2x1		 1x16
1x1		 1x8
2x1
HD Video Playback Yes Yes No No No No No No
SD Video Playback Yes Yes Yes Yes Yes Yes Yes Yes
Audio HDA HDA HDA HDA / AC97 HDA / AC97 HDA HDA HDA
Video Scaling High Quality (5x4) High Quality (5x4) Basic (2x2) Basic (2x2) Basic (2x2) Basic (2x2) Basic (2x2) Basic (2x2)
SATA/PATA drives 6/2 4/2 4/2 4/4 4/4 4/2 4/4 2/2
SATA speed 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s 3Gb/s
RAID 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1,0+1,5 0,1
NVIDIA MediaShield storage technology Yes Yes Yes Yes Yes Yes Yes Yes
Ethernet 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100
USB ports 12 12 10 8 10 10 10 8
